交流輸入   AC Input

電壓：150V,30V,600V，電流：1A,5A

輸入負載   Input burden

電壓：≤0.1VA,電流≤0.2VA

輸入過載   Input over load

750Vrms,持續

超負荷       Capacity

可承受2倍于額定值(連續),10倍于額定值(10S)

精度           Accuracy(23±5℃)

±0.2%R.O.

響應時間   Response time

<0.4sec.

輸出波動   Output Ripple

<0.5% of R.O.

輸出電壓   Output Voltage

0~10V，負載電阻=輸出電壓÷10mA

輸出電流   Output Current

0~20Ma，負載電阻=10V÷輸出電流

溫度范圍   Temp.Range

存放溫度-20℃~70℃,工作溫度0℃~50℃

溫度系數   Temp. Coefficient

100ppm at23℃±3℃

濕度范圍    Humidity range

≤95%R.H(濕度)

隔離            Isolation

輸入/輸出/電源/外殼

振動測試    Surge test

DIN-IEC255-4 ANSI C37

耐壓測試    Dielectric test

DIN-IEC688 2K Vrms/1 min

外殼材料    Housing material

ABS Plastic(The case can bemounted on a 35mm rail which complies with DIN 46277)

安裝            Mounting

DIN rail or wall mounting

使用電源    Power Supply

AC115/230V±15%,50/60Hz,3VA DC24V,48V,120V(可訂制)

外形尺寸    Dimension

55(L)×80(W)×120(H)mm---signal phase

110(L)×80(W)×120(H)mm---3phase
